Technical Specifications

Tachometer/Frequency
Mode
Counter Mode
AC Voltage Input
Magnetic Sensor Input
NAMUR Sensor Input
NPN/PNP Sensors Input
TTL/24V Encoder Input
Switched Contact Input
Accuracy at 23ºC ±5ºC
Power Supply and
Fuses
Power Consumption
Sensor Excitations
User Manual - DPM3-P Series Digital Panel Meters
Technical Specifications
Maximum Frequency
Minimum Frequency
Without totalizer
With totalizer
Range
Sensitivity
R
C
I
ON
I
OFF
R
C
Logic level "0"
Logic level "1"
Logic level "0"
Logic level "1"
V
C
R
C
F (auto selection of input type prog.)
C
Frequency / Tachometer
Chronometer
Temperature coefficient
Warm-up time
-H High Voltage:
-L Low Voltage:
DPM3-P User Manual, 1st Edition
20kHz (without totalizer)
Vin (AC) > 60mVpp for f < 1 kHz
> 120 mVpp for f > 1 kHz
20Hz with duty cycle 50%
10Hz with duty cycle 30%
85-265 VAC 50/60 Hz or 100-300 VDC, (recommended fusing 0.5A/250V, 5mm x 20mm
glass miniature or DIN 41661 equivalent)
22-53 VAC 50/60 Hz or 10.5 - 70 VDC, (recommended fusing 2A/250V, 5mm x 20mm
glass miniature or DIN 41661 equivalent)
5W, 8W for -A2R
8.2 VDC @ 30mA ; 20VDC (not stabilized) @ 100mA
8kHz (with totalizer)
1kHz (duty)
0.01 Hz
11kHz
9kHz
10 to 300 VAC
3.3 kΩ
< 1mA DC
> 3mA DC
3.3 kΩ
< 2.4 VDC
> 2.6 VDC
< 2.4 VDC
> 2.6 VDC
5V (internal)
3.9 kΩ
0.005%
0.01%
50ppm / ºC
5 minutes
