Table of programmable functions

• No.: Number to select the function.
• Function: Function name.
• Description: Description and characteristics of the function.
• Activation by:
No. Function
0
Deactivated
1
OFFSET
2
RESET OFFSET
3
RESET VARIABLES
4
SEE VARIABLES
5
Deactivated
6
HOLD DISPLAY
7
BRIGHTNESS
8
COLOR
9
SETPOINT / OFFSET VALUE
10
FALSE SETPOINTS
11
REMOTE KEYBOARD*
12
START / STOP
* All 3 logic inputs must be programmed with function 11.
30
Falling edge: the function is activated applying a falling edge to the
corresponding pin with respect to common.
Low level: the function will remain activated as long as the corresponding pin
is held at a low level.
Description
None
Take the value of the display as offset
Reset the offset memory
Resets the value of the variable (ProC, totAL, PEAK, VAL)
Displays the value of the variable (ProC, totAL, PEAK, VAL)
None
Fix the display value
Changes the brightness of the display alternating between Hi and Lo
Change the color of the display (RED, GREEN, AMBER)
Presents the value to program in (OFFSEt, SEt1, SEt2) In this mode, the
input also acts as an ENTER key
Simulates that the meter has an option of 4 setpoints installed
InP1 = ENTER, InP2 = SHIFT, InP3 = UP
Start / Stop Chronometer in A mode, or Stop Counter / Totalizer
DPM3-P User Manual, 1st Edition
Activation By
None
Falling edge
Falling edge
Falling edge
Low level
None
Low level
Low level
Low level
Falling edge
Low level
Low level
Low level
