User Manual - DPM1 Series Panel Meters

Technical Specifications

Input
Sensor Excitation
Accuracy Conditions
Conversion
Display
Relays
Analog Output
(0/4-20mA Sourcing)
(Models DPM1-A-A2R-H &
DPM1-A-A2R-L only)
Power Supply and Fuses
Filter
Environmental Conditions
Environmental Air
Agency Approvals
24
Technical Specifications
Range
±10V
±60V
±100mV
±20mA
Temperature coefficient
Warm-up time
Temperature
Technique
Resolution
Conversion rate
Range
Type
LEDs
Display refresh rate
Display / Input overrange indication
Relays refresh, maximum and
minimum value
2 Relays (Form A) SPST normally
open
Resolution
Accuracy
Temperature coefficient
Maximum load
DPM1-A-2R-H, DPM1-A-A2R-H
DPM1-A-2R-L, DPM1-A-A2R-L
Cutoff frequency
Slope
Operating temperature
Storage temperature
Relative humidity (non condensing)
Maximum altitude
Frontal protection degree
DPM1 User Manual, 1st Edition
Resolution Input Impedance
1mV
3mV
10µV 100MΩ
1µA 12.1Ω
20V±5VDC @ 30mA
100ppm/°C
15 minutes
23°C±5°C
Sigma-Delta
±15 bits
25 times per second
-1999 to +9999, selectable decimal point position
4 digit 8mm (0.31), red
Relay 1, Relay 2, Tare, Programming Mode
5 times per second
"-OuE" , "OuE"
10 times per second
5A@250VAC / 30VDC
5.5µA
±(0.3% rdg+40µA)
3µA/°C
≤500Ω
85-265VAC 50/60Hz or 100-300VDC
(Recommended fusing 0.2A/250V, DIN 41661)
21-53VAC 50/60Hz or 10.5-70VDC
(Recommended fusing 1.0A/250V, DIN 41661)
0.4Hz to 0.004Hz
20dB/Dec.
-10ºC to +60ºC (14ºF to 140ºF)
-25ºC to +85ºC (-13ºF to 185ºF)
<95% @ 40ºC (104ºF)
2000m
IP65
No corrosive gases permitted
CE
Accuracy
1MΩ ±(0.1% rdg+3mV)
1MΩ ±(0.1% rdg+18mV)
±(0.1% rdg+30µV)
±(0.1% rdg+6µA)
