Motorola MTR2000 T5544 Instruction / Field Service Manual page 65

55.9 cm
(22 in)
46.5 cm
(18.3 in)
45.2 cm
(17.8 in)
FRONT VIEW
9.6 cm
(3.8 in)
49 cm
(19.3 in)
68P81096E37-N
06/28/05
5.1 cm
5.1 cm
(2 in)
(2 in)
5.1 cm
5.1 cm
(2 in)
(2 in)
BASE MOUNTING DETAIL
Figure 1. Floor-mount Cabinet – Dimensions and Clearances
FRONT
1.524m
(60 in)
1.168m
(46 in)
76.2 cm
(30 in)
0.64 cm
(0.25 in)
5.1 cm
9.2 cm
(2 in)
(3.625 in)
holes (2)
VIEWED FROM
TOP
1.575 cm
5.1 cm
(0.62 in)
(2 in)
holes (4)
55.9 cm
(22 in)
46.5 cm
(18.3 in)
Brackets (2)
Mounting
SIDE VIEW
Rails (4)
5.1 cm 9.6 cm
(2 in) (3.8 in)
49 cm
(19.3 in)
5.1 cm
(2 in)
Installation
Station
Support
7
