AccuPlot and AccuJet Maintenance
T
O INSTALL THE CARTRIDGE IN YOUR PLOTTER
WARNING: F
AILURE TO DISABLE SERVO POWER BEFORE PUTTING YOUR HANDS IN
OR NEAR THE PLOTTING AREA COULD RESULT IN INJURY
1. Insert the pen into the pen holder.
2. Insert the ink reservoir into the large round opening in the cover. Line up
the guide on the side of the ink reservoir with the notch in the large round
opening.
3. Hold the beam assembly to keep it from bending and press the reservoir
down firmly. This will secure the reservoir.
4. Turn the reservoir 90 degrees clockwise by one-quarter turn to lock the
reservoir in place.
5. Thread, by turning, the pen holder cap to the top of the pen holder.
Installation is complete.
5-20
.
Plotter Pen Maintenance
