Offline Operation
Inkjet Head Rotation
T
O TEST THE ROTATION OF THE INKJET HEAD
1. From page one of the Diagnostics menu, press the Menu key twice to
display page three.
2. Press F1-Inkjet Diags.
3. Press F2-Rotate.
4. Use the arrow up and arrow down keys to rotate the head to any position
from -90 to +90 degrees from its home position. The current rotation
appears below the menu title.
5. Press the F3 key to select a positive (+) or negative (-) rotation.
6. Do one of the following:
7. Press F4-Exit to return to page two of the Inkjet Diag menu.
4-36
INKJET DIAGS
TEST JETS
ROTATE
ROTATE INKJET HEAD
START
CONTINUOUS
•
Press F1-Start to rotate the head to the selected angle.
•
Press F2-Continuous to cycle the head position between home
and the selected angle. You must press F4-Stop to discontinue
this test and return to the rotate inkjet head menu.
DIAGNOSTICS. . .
INKJET DIAGS. . .
=/- ## DEGREES
EXIT
OFFSET
EXIT
SIGN +/-
EXIT
Diagnostic Tests
