Reversing the Take-up Roll

Reversing the Take-up Roll
The Reverse function turns the take-up roll clockwise, making it easy to cut off
a plot.
T
O REVERSE THE TAKE
1. Raise the three paper grippers.
2. Press F3-P
menu.
3. Press F3-R
"Reversing Paper" displays briefly, then the Paper Advance screen
reappears.
4. Using a utility knife, cut the plot off at the point where it finishes
unwinding from the take-up roll.
5. Trim the other side of the plot with the utility knife and tape the free end
of the paper back onto the take-up roll.
6. Put the grippers back into position.
Reversing the Take-up Roll
-
UP ROLL AND CUT OFF A PLOT
A from the Offline menu to display the Paper Advance
APER DV
PAPER ADVANCE
PAGE
MANUAL
. The paper automatically reverses. The message
EVERSE
REVERSE
EXIT
