Offline Operation
6. When finished, return to page one of the Offline menu and initialize the
plotter.
Default Table Parameters
Table 4-1 shows the plotter Table parameters. The parameters appear on the
control panel screen in the order they are listed in the table. Follow the
instructions starting on page 4-12 to adjust the values for these parameters.
T 4-1
ABLE
parameter
X Origin Position
Y Origin Position
X Table Size
Y Table Size
X Step Size
Y Step Size
NOTE: NOTE: You may want to decrease the Y Table Size value if you plan to use shorter
width paper rolls.
4-14
P T P
LOTTER ABLE ARAMETERS
function
Sets default X-axis origin position.
Sets default Y-axis origin position.
Sets default X-axis table
dimension.
Sets default Y-axis table
dimension.
Used for development or field
service.
Used for development or field
service.
default
AJ-520 = 00.17 inches
AP-100, 300, 320, 360 = 00.00
inches
00.00 inches
AJ-520 = 17.20 inches
AP-100, 300, 320, 360 = 16.50
inches
AJ-520 = 85.80 inches
AP-100 = 61.1 inches
AP-300, 320 = 78.8 inches
AP-360 = 94.6 inches
AJ-520 = 0.7305 mils/cnt
AP-100, 300, 320, 360 = 0.7282
mils/cnt
0.6725 mils/cnt
Plotter Parameters
