Offline Operation

Raising and Lowering the Pen

Raising and Lowering the Pen
Tool Up/Tool Down is a toggle function that raises and lowers the pen.
The menu displays the action to be performed, not the current position of the
pen. For example, if the pen is raised, the menu displays Tool Down. If the
pen is lowered, the menu displays Tool Up.
T
O LOWER OR RAISE THE PEN
1. From page one of the Offline menu, press the Menu key one time to
display page two.
2. From page two, press F1-T
If the pen was up, it lowers to the paper and the Offline menu display
changes as shown below.
If the pen was down, it lifts off the paper and the Offline menu display
changes as shown below.
Raising and Lowering the Pen
OOL
TOOL UP
PARAM ENTRY
TOOL DOWN
PARAM ENTRY
U /D .
P OWN
OFFLINE . . .
SERVO DISABLE
OFFLINE . . .
SERVO DISABLE
TOOL TMR
TOOL TMR
4-7
