AccuPlot and AccuJet Maintenance

Using Paper Width Adapters

To use a paper roll that is less than the maximum width for a plotter, you must
install paper width adapters on both the supply roll and the take-up roll.
T
O INSTALL PAPER WIDTH ADAPTERS
1. Slide the adapter onto the supply roll bar and adjust it so that the
larger diameter is flush with the edge of the paper roll. Secure the
supply roll adapter by tightening the set screw with a 3 mm hex
wrench.
2. Slide the adapter onto the take-up roll bar so that the smaller diameter
is flush with the paper core. Secure the adapter by tightening the set
screw with a 3 mm hex wrench.
Loading Plotter Paper 5-13
