Offline Operation
Diagnostic Plots
Diagnostic plots are a series of simple test plots used for troubleshooting.
Some of the tests allow you to check plotter accuracy by measuring the
printed plots. The Diagnostic Plots menu has three pages. From pages one and
two, you can perform pen tests. From page three you can test Inkjets.
T D
O DISPLAY
1. From page one of the Diagnostics menu, press F1-Diag Plots to display
page one of the Diag Plots menu (pen plots).
2. Press the menu key once to display page two (more pen plots).
3. Press the menu key once more to display page three (Inkjet test plots).
NOTE: NOTE: Plot tests are described in Table 4-6 on page 4-31.
Diagnostic Tests
P
IAGNOSTIC LOTS MENUS
PEN DN-45
PEN UP-45
16 X 32
LIFE TEST
INKJET DIAG PLOTS
FONT TEST
OFFSET TEST
PEN PLOTS
PAGE TEST
PEN PLOTS
FONT TEST
EXIT
EXIT
MULTI DIR
EXIT
4-29
