Offline Operation
Default Plot Parameters
Table 4-2 shows the AccuJet Plot parameters. The parameters appear on the
control panel screen in the order they are listed in the table. Follow the
instructions starting on page 4-12 to adjust the values for these parameters.
T 4-2
ABLE
parameter
Plot Velocity
Plot Acceleration
Annotation
Acceleration
Annotation Velocity
Pen Up Delay
Pen Down Delay
NOTE: NOTE: The default settings for Plot Velocity and Annotation Velocity are the
maximum allowed for these parameters. For very precise, plotting you may
want to use slower velocity and acceleration values.
Plotter Parameters
A J P P
CCU ET LOT ARAMETERS
function
Sets maximum velocity along
X–axis and Y–axis.
Sets acceleration rate along X–axis
and Y–axis.
Sets acceleration rate of
characters being drawn, when
using pen for annotation.
Sets velocity of characters being
drawn, when using pen for
annotation.
Ssets amount of time the plotter
delays after lifting pen.
Sets amount of time the plotter
delays after lowering pen.
default
66 in/sec
AJ-520 = 2.0 Gs
AP-100, 300, 320, 360 = 2.5
Gs
AJ-520 = 2.0 Gs
AP-100, 300, 320, 360 = 2.5
Gs
66 in/sec
1 20 msec intervals
2 20 msec intervals
4-15
