Offline Operation
Default Miscellaneous Parameters
Table 4-4 shows the plotter miscellaneous parameters, their function, and the
GGT default setting for each. The parameters appear on the control panel
screen in the order they are listed in the table. Follow the instructions starting
on page 4-12 to adjust the values for these parameters.
T 4-4
ABLE PLOTTER
parameter
Language
Font Type
Character Set
Annotate With
Inkjet
Pen Up Velocity
Pen Up
Acceleration
Plotter Parameters
M P
ISCELLANEOUS ARAMETERS
function
Sets menu language from standard
to alternate.
0 = standard
1 = alternate
Sets style of font used in plotting.
0 = fast
1 = elaborate
Sets character used for plotting to
the downloaded set.
0 = standard
1 = alternate
Prints all annotation with the inkjet
head, overriding any tool selection
command sent from your marker
making system.
0 = no
1 = yes
Sets velocity limit for pen up
movement.
Sets acceleration limit for pen up
movement.
default
0 – STD
0 – FST
0 – STD
0 – NO
66 in/sec
AJ-520 = 2.0 Gs
AP-100, 300, 320, 360 = 2.5
Gs
4-17
