Plotter Hardware Components

Main Power Panel

Main Power Panel
The main power panels includes the on/off switch and data connectors.
Figures 3-3 and 3-4 show the power panels for the AccuPlot and the AccuJet
plotters.
Main Power Switch
Computer

Figure 3-3 AccuPlot 100/300 Power Panel

Far end of the supply roll.
Computer

Figure 3-4 AccuJet 520 Power Panel

3-4
Far end of the paper roll
Line Power
Main Power Switch
Line Power
Main Power Panel
