Offline Operation
T
O TEST JETS
1. From page one of the Diagnostics menu, press the Menu key twice to
display page three.
2. Press F1-Inkjet Diags.
3. Press F1-Test Jets to display the Test Jets menu.
4. Press F1 to choose a bank of jets.
NOTE: NOTE When you press F1, the menu item changes to show the bank not currently
chosen.
5. Press F3-Fire to test the entire bank. Verify the plotter draws a vertical line.
6. Press F2-Set Jets to select individual jets. The number of the current jet
appears on the screen, just under the menu title.
4-34
INKJET DIAGS
TEST JETS
ROTATE
TOGGLE BANK
SET JETS
NEXT JET
PREV JET
DIAGNOSTICS. . .
INKJET DIAGS . . .
TEST JETS
SET JETS
####
EXIT
OFFSET
EXIT
FIRE
EXIT
TOGGLE
EXIT
Diagnostic Tests
