Offline Operation
Default Inkjet Parameters
Table 4-5 shows the plotter Inkjet parameters, their function, and the GGT
default setting for each. The parameters appear on the control panel screen in
the order they are listed in the table. Follow the instructions starting on page
4-12 to adjust the values for these parameters.
T 4-5
ABLE
parameter
Inkjet Velocity
Inkjet Acceleration
Inkjet Strike Count
Offset Test DIM A
Offset Test DIM B
Offset Test DIM C
Offset Test DIM D
X Pivot Offset
Y Pivot Offset
X Jet 1 Offset
Y Jet 1 Offset
IJ C Axis Home State
Offset Parameter Values
Values for Offset Test and Pivot Offset parameters are unique to each machine
and must be set individually using the procedure on page 4-12. Do not leave
the offset values at zero. Offset values of zero result in annotation printed with
the inkjet extremely out of position.
4-18
I P
PLOTTER NKJET ARAMETERS
function
Sets maximum velocity along the X and Y-
axes to be used for printing with inkjet.
Sets maximum acceleration along the X and
Y-axes to be used for inkjet printing.
Sets the number of passes on a character.
Higher value makes a darker annotation.
Used for development or field service.
Used for development or field service.
Used for development or field service.
Used for development or field service.
Used for development or field service.
Used for development or field service.
Used for development or field service.
Used for development or field service.
1, 2, 3, or 4
default
24 in/sec
2 Gs
1 strike(s)
0 inches
0 inches
0 inches
0 inches
0 inches
0 inches
0 inches
0 inches
+ 1
