Setting the Pen and Inkjet Timers

Setting the Pen and Inkjet Timers
The Tool Timer function allows you to see the time remaining in the life of the
pen, check the remaining inkjet capacity, and reset the pen life and cartridge
life values.
The pen timer tracks the amount of distance that the pen tip has been in
contact with the paper. This is important if your plotter runs unattended. If you
set the pen timer (at the parameter entry screen), the plotter automatically
stops when the distance expires.
T
O SET THE PEN TIMER
1. From page one of the Offline menu, press the Menu key one time to
display page two.
2. From page two of the Offline menu, press F4-Tool Tmr to display the tool
timer menu.
3. Press F1-Pen Timer to see the current values.
4. Do one of the following:
•
•
5. Press F4-Exit until you reach page one of the Offline menu.
6. From page one of the Offline menu, press F2-Initialize to load the new
timer value.
Setting the Pen and Inkjet Timers
TOOL TIMERS
PEN TIMER
INKJET TIMER
DISTANCE REMAINING
NEW PEN
TIMER ON
Press F1-New Pen to restart the timer after installing a new pen.
Press F2-Timer On to enable the timer.
xxxxx YARDS
EXIT
EXIT
