the computer using a USB cable. The computer will automatically recognize the Collider, which will
be identified as "One Series Collider Delay+Reverb" in the operating system.
USB connectivity brings many benefits, such as the ability to connect with the Neuro Desktop Editor
for downloading Collider firmware updates, accessing an advanced set of effect editing parameters,
and downloading alternate reverb engines. The USB port is also provides MIDI connectivity to audio
production software.
USB-MIDI
The Collider will appear as a MIDI device in your computer's operating system. As a result, the
Collider can communicate with audio production software that utilizes MIDI, such as Pro Tools,
Ableton Live, Logic Pro, and more. MIDI messages can be sent directly to the Collider using the USB
connection, which allows for full automation of the Collider within host software such as a DAW. For
example, the depth or speed of the LFO can be automated by outputting MIDI continuous controller
messages from the host software to the Collider via the USB connection. For more details, see
Implementation.

Specifications

Dimensions
•
Length: 11.63 cm (4.58 inches)
•
Width: 11.17 cm (4.40 inches)
•
Height (not including knobs and footswitches): 3.71 cm (1.46 inches)
•
Height (including knobs and footswitches): 5.61 cm (2.21 inches)
Weight
•
450 grams (1 pound)
Power
•
300mA @ 9V DC
•
Center negative, Barrel positive plug, 2.1 mm inner diameter, 5.5 mm outer diameter
Audio Performance
•
Maximum Input Level: +6.54 dBV = 8.76 dBu = 2.12 V RMS = 6.0 V p-p
•
Full Scale Output Level: +6.54 dBV = 8.76 dBu = 2.12 V RMS = 6.0 V p-p
•
Input Impedance: 1 Mega Ohm (1 MΩ)
•
Output Impedance: 600 Ohm (600 Ω)
•
110 dB DNR Audio Path
•
24-bit Audio Conversion
•
56-bit Digital Data Path
•
Universal Bypass (relay-based true bypass and analog buffered bypass)
