USB connectivity brings many benefits, such as the ability to connect with the Neuro 3 App
and for downloading Artifakt firmware updates, accessing an advanced set of effect
editing parameters, and downloading community presets. The USB port also supports
MIDI connectivity to a DAW.
USB-MIDI
The Artifakt will appear as a MIDI device in your computer's operating system. As a result,
the Artifakt can communicate with audio production software that utilizes MIDI, such as Pro
Tools, Ableton Live, Logic Pro, and more. MIDI messages can be sent directly to the
Artifakt using the USB connection, which allows for full automation of the Artifakt within
host software such as a DAW.

Specifications

Dimensions
Length: 11.4 cm (4.5 inches)
§
Width: 7.00 cm (2.75 inches)
§
Height (not including knobs and footswitches): 3.71 cm (1.46 inches)
§
Height (including knobs and footswitches): 5.1 cm (2 inches)
§
Weight
§ 280 grams (0.625 pounds)
Power
200mA @ 9V DC
§
Center negative, Barrel positive plug, 2.1 mm inner diameter, 5.5 mm outer
§
diameter
Audio Performance
Maximum Input Level: +6.54 dBV = 8.76 dBu = 2.12 V RMS = 6.0 V p-p
§
Full Scale Output Level: +6.54 dBV = 8.76 dBu = 2.12 V RMS = 6.0 V p-p
§
Input Impedance: 1 Mega Ohm (1 MΩ)
§
Output Impedance: 600 Ohm (600 Ω)
§
110 dB DNR Audio Path
§
24-bit Audio Conversion
§
56-bit Digital Data Path
§
Universal Bypass (relay-based true bypass or analog buffered bypass)
§
Source Audio Artifakt Lo-Fi Elements User Guide 35
