SCOOP enabled with GRIT enabled:
There is a mild interaction between GRIT and SCOOP which results in a smoothing out of the boosted
treble frequencies with an earlier peak and a flatter curve. The severity of the treble boosting
happening in the SCOOP circuit is reduced by just over 1dB when GRIT is enabled in this instance.

Specifications

Dimensions
•
Length: 4.13 inches (105mm)
•
Width: 3.07 inches (78mm)
•
Height: 1.54 inches (39mm)
•
Weight: 0.45kg / 1lbs
Power
•
140mA (without headphone input) / 200mA @ 9VDC
SA272
* * *
ZIO Analog Bass Preamp + D.I. User Guide 13
