General Specifications; Hardware Specifications - ELCOM Euro-50 Service Manual

Euro-50
Power supply
Internal accumulator
Range of input supply voltage and current drawn
Maximum consumption of external equipment powered from the cash register -
COM1
Operational temperature
Long-term storage conditions (more than 30 days)
Short-term storage conditions (fewer than 30 days)
Dimensions
Weight
• Microcontroller STR911FAW44X6 operating at a frequency of 16MHz
• Memory SRAM 128kB and RTC backup Li battery 3.0V/250mAh
• I2C interface for connecting to fiscal memory 128/256/512KB
• I2C interface for connecting 2 internal displays (character and segmented)
• Thermal printer LTPZ245N
• COM1 RS232 (RxD, TxD, GND, 5V)
• COM2 RS232 (RxD, TxD, GND)
• USB 2.0 slave
8
1.1. General specifications
1.2. Hardware specifications
Service manual
Power adapter S012BV1200100
100-240V~50/60Hz, 12V/1000mA
7.2V / 2000mAh LiON
12 V = ; 800mA max.
500 mA
0~40ºC, 30~85% RH
0~25ºC, <75% RH
-20~45ºC, <75% RH
243 × 140 × 89 mm
0.65 kg
Elcom s. r. o.
