Euro-50
Printer platen
(M080145)
6. Loosen the screw of the seal and the four screws joining the top and bottom covers of the cash register (two from
above and two from below) and gently separate the bottom, top, rear top and rear bottom parts.
Upper cover
(M040428)
Stick-on
(M040467)
12
Figure 2.3. Paper ribbon holder and the print roller holder.
Printer lever
(M051050)
Platen holder long
(M040442)
Separator
(M040452)
Winding reel
(M040443)
Service manual
Elcom s. r. o.
