ELCOM Euro-50 Service Manual page 75

Euro-50
PCB E50 POWER – BILL OF MATERIALS
ID Designator
1 C1, C2, C11, C12, C13, C15, C17, C20, C23, C24
2 C3
3 C4
4 C5, C7, C9
5 C6
6 C8, C10, C19, C22
7 C14
8 C16
9 C18
10 C21
11 C25
12 FU1
13 L1
14 L2, L3
15 L4, L5, L6
16 L7, L8, L9, L10
17 L11
18 NL1
19 NL2
20 NL3
21 R1, R2, R3
22 R4, R7, R10, R11
23 R5
24 R6, R9
25 R8
26 R12
27 R13
28 R14
29 R15
30 R16
31 R17
32 R18
33 R19
34 R20, R21
35 R22
36 SA1
37 VD1, VD3
38 VD2
39 VT1
40 VZ1
41 VZ2
42 XC1
43 XC2
44 XC3
45 XC4
46 XC5
47
Elcom s. r. o.
Description
Capacitor 100nF X7R 16V 0603
Capacitor 100uF 6,3V SMD D
Capacitor 10nF X7R 16V 0603
Capacitor 100nF 50V 0805
Capacitor 100uF 25V SMD D
Capacitor 10uF X7R 25V 1206
Capacitor 100uF 25V D case low ESR tantalum
Capacitor 1nF X7R 0603
Capacitor 22uF 16V SMD B
Capacitor 100pF 0603
Capacitor 22uF X7R 6,3V 1206
SMD1812 LF Series Surface Mount PTC 24V/1,1A
Coil SMD 10uH DRH5D28R-100N
Coil SMD 15uH DRH5D28R-150N
Ferrite bead ACMS201209A601
Ferrite bead EBMS160808A102
Ferrite bead BCMS201209A121
BQ24123RHLR
LM3489MM/NOPB
TPS62056DGSR
Resistor 100K 5% 0603
Resistor 10K 1% 0603
Resistor 0R12 1% 1206
Resistor 0R68 5% 1206
Resistor 150K 5% 0603
Resistor 270R 1% 0603
Resistor 2R7 1% 0603
Resistor 39K 1% 0603
Resistor 6M8 5% 0603
Resistor 56K 1% 0603
Resistor 2M2 5% 0603
Resistor 18K 1% 0603
Resistor 4K7 5% 0603
Resistor 22K 1% 0603
Resistor 1K 1% 0603
Micro Switch, MDS-12F05-BT
Schottky Diode SK14
MMBZ18VALT1G
FDC5614P
USBLC6-2SC6, USB 2.0 protection
P6SMB18CAT3G
Connector DS-313-13
Connector 1251S-15-SM1
Connector 5075BMR-05-SM-CR
Connector MOLEX 500999-0900
Connector 1251S-09-SM1
PCB E50 PWR v1.2
75
Service manual – Supplements
Package Quantity StockItem
1608 (0603) 10 M120077
IEC SERIES 1680 1 M120109
1608 (0603) 1 M120091
2012 (0805) 3 M120044
CASE D8 1 M120151
3216 (1206) 4 M120154
D Case 1 M120169
1608 (0603) 1 M120103
CASE B 1 M120173
1608 (0603) 1 M120088
3216 (1206) 1 M120156
SMD1812 1 M160016
DRH-R 1 M140026
DRH-R 2 M140027
2012 (0805) 3 M130028
1608 (0603) 4 M130025
2012 (0805) 1 M130026
QFN20 1 M170250
MSOP-8 1 M170255
TSSOP10 1 M170249
1608 (0603) 3 M100204
1608 (0603) 4 M100170
3216 (1206) 1 M100324
3216 (1206) 2 M100195
1608 (0603) 1 M100240
1608 (0603) 1 M100227
1608 (0603) 1 M100247
1608 (0603) 1 M100189
1608 (0603) 1 M100329
1608 (0603) 1 M100327
1608 (0603) 1 M100326
1608 (0603) 1 M100325
1608 (0603) 1 M100237
1608 (0603) 2 M100173
1608 (0603) 1 M100171
MDS-12F05-BT 1 M300016
SMA 2 M110032
SOT23 1 M110108
SuperSOT-6 1 M170259
SOT23-6L 1 M110057
SMB 1 M110109
DS-313 1 M190186
1251S-15-SM1 1 M190200
5075BMR-05-SM 1 M190190
500999-0900 1 M190191
1251S-09-SM1 1 M190199
1 M240228
