2.3 Composition of a method
>dosing drive
drain
>dosing drive
cock direction:
>dosing drive
not over port
2.3.5

Behavior during timeout

parameters
>timeout settings
>timeout settings
SCAN timeout:
When the waiting time has elapsed the function defined below will be carried
out.
>timeout settings
on SCAN timeout:
If
error
sage will be shown. Otherwise the sequence will be continued.
30
port
not over
desc.
Metrohm Sample Processors are designed to communicate with other
instruments. In particular, this includes the coordination between the
Sample Processor and devices connected to it. In the method se-
quence the SCAN command can be used to check whether an instru-
ment is ready or to ask for an acknowledgement after a measurement
has been made. However, it may happen sometimes that problems oc-
cur during a determination run and that the expected signal from the
connected instrument is not received. This is known as a timeout.
This means that it is possible to define a maximum waiting time that will
always be allowed to elapse if a timeout occurs. In addition, the behav-
ior of the Sample Processor when this waiting period has elapsed
(SCAN timeout) can also be defined.
OFF min
off,0...999 min
error
error,continue
is set then the run sequence will be interrupted and an error mes-
1 Define standard air inlet for emptying the
4
Dosing unit
1...4
1 Direction of rotation of Dosino stopcock
auto
auto = cock direction according to shortest path
= never turn beyond port given below
= cock rotation always in descending direction
asc. = cock rotation always in ascending direction
1 Protected port, that it not to be moved
4
over during a stopcock rotation
1...4 (see above)
Submenu for behavior if a SCAN timeout occurs
Open the submenu with <ENTER>
Waiting time if a SCAN timeout occurs
Behavior if SCAN timeout occurs
Metrohm 838 Advanced Sample Processor, Operation
