Metrohm 838 Advanced Sample Processor Manual page 29

>recall rack
beaker sensor:
Not implemented.
>recall rack
rack offset
* )
<LEARN> function.
Special beaker positions
>>recall rack
>>>special positions
Use <QUIT>
Special beaker positions are predefined places on a sample rack that are not
for next higher
treated as sample positions. They can be occupied by rinsing beakers or
level
conditioning beakers and selectively addressed during a run sequence. Up
to 16 special beaker positions can be defined per rack. For each special
beaker the work position of the lift and the beaker radius can be set, see
above.
Selection of special beaker
Rack position of the special
beaker
etc. up to special beaker 16
>rack definitions
>>store rack
In order to store modifications to the definition of a sample rack the submenu
>>store rack
>store rack
name:
With the <SELECT> key you can select one of the existing rack names. The
rack data is stored with <ENTER>. Any rack name can be used. The input
of any rack name can be made directly via the numerical keys or in the text
Metrohm 838 Advanced Sample Processor, Operation
Tower, SwingH, off
-5.00...0.00...5.00°
All the above lift positions and the rack offset can be set by using the
is selected.
6.2041.310
10 ASCII characters
Selection of the beaker sensor
off
Correction for the rotation angle of the
0.00°
sample rack *
Submenu special beaker positions
Open with <ENTER>
>>>special positions
special beaker
>>special positions
rack position
Save rack definitions
Name of rack
2.2 Configuration
)
1
1...16
1
0
0...number Pos.
0 = not defined
21
