Swing angle for external posi-
tion 1 *
The swing angle for the external positions is entered as an abso-
lute angle. The input limits are defined by the offset of the Swing
Head drive (approx. 9°) and the set max. swing angle range.
Setting the working height for
external position 1 *
Swing angle for external posi-
tion 2 *
... up to external pos. 4
* can be set with LEARN function
Metrohm 838 Advanced Sample Processor, Operation
)
)
)
>>swing head 1
external pos.1
Offset...84.00...max. angle+offset
0° = points to rack center
>>swing head 1
work position1
>>swing head 1
external pos.2
2.2 Configuration
117.00°
0 mm
0...235 mm
117.00°
