H1 Pictorial Diagram - Danfoss H1 Series Technical Information

Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
H1 general information

H1 pictorial diagram

14
15
2
© Danfoss | December 2016
3
7
9
4
8
7
Working loop A (Low pressure) and charge pressure
Working loop B (High pressure)
Servo pressure
Case drain
Suction
1. Bent Axis Variable Displacement Motor
2. Axial Piston Variable Displacement Pump
3. Electric Displacement Control (EDC)
4. Charge Pump
5. Charge Check / High Pressure Relief Valve
6. Loop Flushing Valve
7. Pressure Limiter Valve
8. Charge Pressure Relief Valve
9. Servo Cylinder
17
5
6
18
10
5
10. Charge Pressure Filter
11. Heat Exchanger
12. Heat Exchanger Bypass Valve
13. Valve Segment
14. Pump Swashplate
15. Input Shaft
16. Output Shaft
17. Reservoir
18. to Motor Case
11037153 | BC00000043en-US1103 | 9
12
11
13
16
1
P003 423
