H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
H1 general information

H1 system schematic

System schematic H1 pump and H1 motor with EDC
M14
C2
F00B F00A
M5
M4
The schematic above shows the function of a hydrostatic transmission using an H1 axial variable displacement pump with electric
proportional displacement control (EDC) and an H1 bent axis variable displacement motor with electric proportional control (L*) and
integrated loop flushing device.
10 | © Danfoss | December 2016
M6 1 2
R1
C1
CW
S L3 L4
max. 3 bar
[43.5 psi]
M3 L1 L2 MA
A
A
B B
MB
L2
max. min.
M4 M5
11037153 | BC00000043en-US1103
MA N
n
L1
MB
P003 424
