3.2 Chipset

The cPCI-6525 incorporates the Intel® QM77 Platform Controller
Hub (PCH).
Intel® QM77 Platform Controller Hub
PCI Express Base Specification, Revision 2.0 support for up
to eight ports with transfer rate up to 5 GT/s
Supports dual display
ACPI Power Management Logic Support, Revision 4.0a
Enhanced DMA controller, interrupt controller, and timer
functions
Integrated Serial ATA host controllers with independent
DMA operation on up to six ports and SATA 6.0 Gb/s up to
two ports
Supports USB 2.0, USB 3.0
USB host interface with two EHCI high-speed USB 2.0 Host
controllers and two rate matching hubs provide support for
up to fourteen USB 2.0 ports
Integrated 10/100/1000 Gigabit Ethernet MAC with System
Defense
System Management Bus (SMBus) Specification, Version
2.0 with additional support for I2C devices
Supports Intel Trusted Execution Technology
Support vPro Technology
Support Active Management Technology
Support AMT Version
Support Anti-Theft Technology
Supports Intel® High Definition Audio
Supports Intel® Rapid Storage Technology
Supports Intel® Virtualization Technology for Directed I/O
Low Pin Count (LPC) interface
Serial Peripheral Interface (SPI) support
Functional Description
