Specifications

2.1 cPCI-6525 Blade Specifications

CompactPCI®
Standards
Mechanical
Processor
Chipset
Memory
CompactPCI
Bus
Graphics
BIOS
Gigabit
Ethernet
Table 2-1: cPCI-6525 Blade Specifications
Specifications
• PICMG® 2.0 CompactPCI® Rev. 3.0
• PICMG® 2.1 Hot Swap Specification Rev.2.0
• PICMG® 2.9 System Management Bus Rev. 1.0
• PCIMG® 2.16 Packet Switching Backplane Rev.1.0
• Standard 6U CompactPCI®
• Board size: 233.35mm x 160mm
• Single-slot width (4HP, 20.32mm)
• CompactPCI® connectors with J1, J2, J3, J4 and J5
• UHM connector at J4 for PCIe x16 high speed transmission
(optional)
22nm FCBGA Intel® Core™ i7 Processor
• 4-core Intel® Core i7-3615QE Processor, 2.3 GHz, 6MB L3
cache, TDP 45W
• 4-core Intel® Core i7-3612QE Processor, 2.1 GHz, 6MB L3
cache, TDP 35W
• Passive heatsink
• Intel® BD82QM77 Platform Controller Hub (PCH)
• Dual channel DDR3-1066/1333/1600 SDRAM with ECC,
total up to 16GB
• One channel in SODIMM sockets up to 8GB
• One channel soldered onboard up to 8GB (dependent on
availability of memory modules and chips)
• PCI 32/64-bit, 33/66MHz; 3.3V, 5V universal V(I/O)
• Supports operation in system slot as master or in peripheral
slot as standalone blade without connectivity to
CompactPCI bus (Satellite mode)
• Integrated in processor
• Two dual mode DisplayPorts on front panel with
DVI/VGA/HDMI support by adapter cable
• One DVI, eDP and VGA routed to rear
• AMI EFI BIOS, 64Mbit SPI flash memory
• Two front panel GbE ports from Intel® 82579LM and
82574IT, switchable to rear
• Two rear IO GbE 10/100/1000BASE-T ports by Intel
82574IT GbE controller (PICMG 2.16 support)
