cPCI-6525
1.2 Features
6U CompactPCI® processor blade in 4HP width form factor
Quad-core 3rd Generation Intel® Core™ i7-3615QE
2.3GHz, 6MB L3 Cache, 45W TDP, FCBGA package
Mobile Intel® QM77 Express Chipset (Intel® BD82QM77
PCH)
Dual channel DDR3-1066/1333 ECC SDRAM up to 16GB,
one channel soldered up to 8GB, one channel SO-CDIMM
up to 8GB
32/64-bit, 33/66MHz CompactPCI® Interface based on PCI
specifications, universal V(I/O)
Supports Satellite Mode operation as a standalone blade in
peripheral slots
Three USB 3.0 ports from PCH
SATA 6 Gb/s direct connector for onboard 2.5" drive
CFast slot via adapter board
8x general purpose user programmable LEDs on front
panel (default: Port 80 status)
One DVI-I on front panel with RGB signal switchable to rear
and two additional DVI routed to rear
Two GbE ports on front panel via Intel® 82574IT and
82579LM, switchable to rear
Two Gigabit Ethernet ports to rear via Intel® 82574IT con-
trollers
Compliant with PICMG 2.0, 2.1, 2.9, 2.16 standards
Atmel AT97SC3204 TPM support (optional)
Eight SAS/SATA ports supported by LSISAS3008 when
mated with cPCI-R66S0 RTM
MXM PCIe x16 graphics when mated with cPCI-R66G0 and
cPCI-R66N0
Introduction
3
