IP CAMERA USER MANUAL
The next tab is "IP Change Notification Config": If you have used DHCP and you need to be
notified that the IP Address assigned to the camera was changed, enable it and set Email or
FTP for the notification process.

4.6.2 Port

1. Go to "Network" "Port" to see the interface as shown below.
→
2. Input port number for IE access in the "HTTP Port" textbox.
3. Input the port number for audio & video transmission in the "Data Port" textbox.
4. Set the RTSP port for video/audio transmission over RTSP
5. Set the HTTPS port in case that you wish to use Secured HTTP connection.

4.6.3 Server Configuration

Go to "Network"→ "Server".
This section refers to "Auto Report Server". Enable it if required.
Auto report server will make the camera to report back to the defined server using the port
2009.
Set the port (default port is 2009. It is advisable not to change it.) Set the server address
(usually it is the CMS address which needs to be a static address). Set a unique device ID.
Each of the devices using auto server report should have its own ID.
The Camera will report back to the defined server its current IP using port 2009.
