2. Alarm out has 3 modes as described below:
A. Alarm Linkage (Shown Above): This mode will set the alarm out to be triggered as
a response to any of the available alarms (Motion, Alarm in, Analytics). If this
mode is chosen you will need to set it properly.
Parameter
Alarm Out Name
Alarm Holding Time
B. Manual Mode: This mode will enable you to manually operate the relay.
C. Schedule mode: This mode allows you to set the relay condition according to a
pre-defined schedule.
Once chosen you will have to set the schedule. The set schedule will be relevant for
all weekdays and cannot be set for each day independently.
3. Press the "Save" button to save the settings.
IP CAMERA USER MANUAL
Meaning
You can set a unique name for easy identification.
The holding time means that the alarm signal will stay
active and no additional alarms will be generated
during that time.
