IP CAMERA USER MANUAL

2.1.2 Direct Access through IE

The default network settings are as shown below:
IP address: 192.168.226.201
Subnet Mask: 255.255.255.0
Gateway: 192.168.226.1
HTTP: 80
Data port: 9008
You may use the above default settings when you log in the camera for the first time.
① You can use the IP manager to access the camera even if the camera is still using the
default IP address. Double click on the IP address within the IP manager for the system to pop
up IE browser and connect to the IPC. IE browser will auto download the Active X control.
You must install it in order for the camera to work. After successful installation, a login
window will appear.
You can then set the IP address from the camera configuration menu.
② If you wish to access the camera using its default IP address you will have to manually set
the IP address of the PC to be in the same IP segment as the default settings of the IP camera.
Open the network and sharing center. Click "Local Area Connection" to pop up the following
window.
Select "Properties" and then select internet protocol according to the actual situation (most
probably you are using IPv4). Next, click "Properties" button and set the network of the PC as
shown below.
