Input Service: To enable or disable input trigger service.
Trigger Option: To choose open circuit trigger or closed circuit
trigger. "Low" means that connection between door terminal and
GND is closed, while "High" means the connection is opened.
Door Status: To show the status of input signal.
3.8.10. Unlock via Reception in Building Theme
On building theme, users can unlock the relay through pressing
Reception.
Dial Type: Select the dial account, which supported account 1 or
account 2;
Open Relay: When users press reception icon to call, the relay is
triggered.
Note: This feature is often to trigger the signal via relay terminal.
Figure 3.8.10. Reception action in building
