Akuvox S560 Quick Manual

Hide thumbs Also See for S560:

Unpacking

Before using the device, check the device model and ensure that the shipped box includes

the following items:

Handset X 1

Base station X 1

Speaker

Status Light

Plastic wall anchor X 2

Unlock Key

DND Key

Cancel Key

Quick Guide

Plastic wall anchor X 2

S560

Phone cord X 1

Speaker

Hook

Numerical

Keypad

Volume Key

Mute Key

Manage Center

Key

Reset Hole

Microphone

Table of Contents

Do you have a question about the S560 and is the answer not in the manual?

Page 1 S560 Quick Guide Unpacking Before using the device, check the device model and ensure that the shipped box includes the following items: Handset X 1 Base station X 1 Plastic wall anchor X 2 Plastic wall anchor X 2 Phone cord X 1...
Page 2 S560 Quick Guide Installa�on According to the position of cable, drill two holes in the wall, and make sure the distance between these two holes matches the measurement indicated on the ﬁgure.
Page 3 S560 Quick Guide Insert plastic wall anchors into drilled holes. Turn ST4x20 crosshead screws into plastic wall anchors. Do not fully tighten the screws, and leave some space for placing devices. Connect cables to corresponding interface to test device. For further details, see “Device Wiring”...
Page 4 S560 Quick Guide Device Wiring Applica�on Network Topology SIP Video Phone (third party) Network Video Recorder (third party) S560 S560 Door Phone Door Phone...
Page 5 S560 Quick Guide Conﬁgura�on 1.Access the Website: Press and hold # button, the device will announce IP address. Type in the IP address in browser, then enter the username and password to login (both of them are ‘admin’ by default).
Page 6 Quick Guide Notice Information Akuvox S560 ﬁrmware contains third-party open source software under the terms of the GNU General Public License(GPL). Akuvox is committed to meeting the requirements of the GNU General Public License (GPL) and will make all required source code available.
