Unpacking
Before using the device, check the device model and ensure that the shipped box includes the following items:
1 X
S562
1 X
Crosshead screwdriver
2 X
M4x20 crosshead screw
Product Overview
Microphone
1 X
Wall-mounting bracket
1 X
8-Pin cable
2 X
#6-30 Phillips machine screw
S562
Quick Guide
2 X
ST4x20 crosshead screw
1 X
10-Pin cable
2 X
ST3x20 crosshead screw
S562
2 X
M2x5 crosshead screw
1 X
Diode
2 X
Plastic wall anchors
Speaker
Touch Screen

Advertisement

loading
Need help?

Need help?

Do you have a question about the S562 and is the answer not in the manual?

Questions and answers

Summary of Contents for Akuvox S562

  • Page 1 S562 Quick Guide Unpacking Before using the device, check the device model and ensure that the shipped box includes the following items: M2x5 crosshead screw Wall-mounting bracket ST4x20 crosshead screw S562 10-Pin cable Diode 8-Pin cable Crosshead screwdriver ST3x20 crosshead screw...
  • Page 2 S562 Quick Guide Before You Start Tools needed (not included in shipped box) Cat Ethernet Cable Crosshead Screwdriver Voltage and Current Specifications It is suggested that use PoE or 12VDC 1A power adapter to power on device. AWG Sizes and Properties Table...
  • Page 3 5.Use wet cloth clean device surface softly, and then wipe the surface with dry cloth for cleaning the device. 6.If there is abnormal situation of the device, including uncommon sound and smell, please power off the device and contact Akuvox Technical Team immediately. Wiring Interface To protect the device from potential damage caused by over-voltage, it is recommended to wire a diode into the circuit.
  • Page 4 S562 Quick Guide Installation Step 1: Bracket Installation With 86 junction box in the wall Fix the wall-mounting bracket on the 86 junction box with two M4x20 crosshead screws, please ensure the bracket against to wall. Arrow should be upward...
  • Page 5 S562 Quick Guide Without electrical junction box in the wall According to the position of wires, use a 6mm electric drill to make two 20mm-depth holes horizontally. Then insert two plastic wall anchors into the holes. Please make sure that the top of plastic wall anchors can not be higher than wall.
  • Page 6 S562 Quick Guide As picture shown, tilt the device 15°and line up the holes on the back cover with the hooks on the bracket. Press the device into the brackets and slide down. Then push the device until it against the wall.
  • Page 7 1. Akuvox warranty does not cover intentional mechanical damage or destruction caused by improper installation. 2. Do not attempt to modify, alternate, maintain, or repair device by yourself. Akuvox warranty does not apply to damages caused by anyone who is not representative of Akuvox or an Akuvox authorized service provider. Please...
  • Page 8 Information contained in this document is believed to be accurate and reliable at the time of printing. This document is subject to change without notice, any update to this document can be viewed on Akuvox’ s website: http://www.akuvox.com © Copyright 2023 Akuvox Ltd. All rights reserved.
