Left-click on the model to select it and double-click on the Cut icon to set the cut
plane. The direction and position are available for setting.
E.g：
As for a big model or an irregular model, you need to cut it into several parts so as to
reduce the printing limitation and to better the print quality. Look at the model below:
Picture 8-15 is the preview of the model's original placement and Picture 8-16 is the
preview of the model with support structure.
7-15
(7-16) Model with support structure
7-16
(7-17) Looking at the Picture 8-16, we will definitely find that the complex supports
Inventor Ⅱ User Guide | www.flashforge.com
0086-0579-82273989
75
