Replacement of
High-temperature
Extruder for Guider II/ IIs
This guide is only applicable to FLASHFORGE Guider2/2s 3D printer
Amazon.com orders only: 597891915@qq.com
After-Sales Service: support@ff3dp.com
Tel: +86 579 82273989 Web: www.flashforge.com Add: 2/F, No.518, Xianyuan Road, Jinhua, Zhejiang, China
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Flashforge Guider II
Summary of Contents for Flashforge Guider II
- Page 1 Replacement of High-temperature Extruder for Guider II/ IIs This guide is only applicable to FLASHFORGE Guider2/2s 3D printer Amazon.com orders only: 597891915@qq.com After-Sales Service: support@ff3dp.com Tel: +86 579 82273989 Web: www.flashforge.com Add: 2/F, No.518, Xianyuan Road, Jinhua, Zhejiang, China...
-
Page 2: Kit Contents
Kit Contents High-temperature Extruder x 1 Air Guide x 1 Scan RQ code to watch Replacement of High-temperature Extruder video. https://youtu.be/y285mWS104E... - Page 3 WARNING Top Cover of Power down before replace Extruder high-temperature nozzle. Step 1 Remove the three screws fixed the top cover of extruder by using 2.5mm Allen Wrench, Remove the top cover of extruder. * In case cable is brokening,hold cable when remove the top cover.
- Page 4 Step 2 Remove the two screws fixed the Air Guide by using cross screwdriver, Remove the air guide. Screws Screws Air Guide...
- Page 5 Step 3 1. Unplug the blue thermocouple. （②） 2. Loss the two screws fixed the heating tube nest by using straight screwdriver and unplug heating tube nest. （③） 3. Remove the two screws fixed the leveling servo by using cross screwdriver, and remove Servo Nest the servo.
- Page 6 Step 4 Step 5 Remove the nozzle assembly. Loose the screw hided in the back of PCB board by using 2.0mm Allen Wrench. Air Guide Air Guide...
- Page 7 Step 6 Step 7 Install High-temperature Nozzle Assembly. Install red air guide assembly and fixed it by cross screwdriver. High-temperature High-temperature Extruder Extruder Air Guide...
- Page 8 Step 8 Step 9 Tighten the screw hide in the back of PCB Fixed the two screws of leveling servo board by using 2.0mm Allen Wrench. by using cross screwdriver. Servo Servo...
- Page 9 Step 10 1. Plug back the nest of servo. （④、①） Servo Nest 2. Plug the blue thermocouple. （②） 3. Plug two heat tube nest and fixed by 2 Blue Thermocouple using straight screwdriver. （③） Heating Tube Heating Tube Heating Heating Tube Tube...
- Page 10 Top Cover Step 11 Cover up the extruder top coverFixed the top cover by using 2.5mm Allen Wrench. Finished Cable...
