Attach the upper pole

1. Screw the pole connector onto the lower pole.
2. Attach the other cable-management clip to the upper pole.
3. Screw the upper pole into the pole connector. (figure 5)
figure 5
4. Use the 3 mm hex key to tighten the two screws in the side of the pole connector.
(figure 6)
figure 6
3 mm hex key
Instruction manual
Pole connector
Upper pole
Cable-management clip
Lower pole
9
Pole connector
