Attach The Upper Pole - StarTech.com ARMBARQUAD Instruction Manual

4. Use the 5 mm hex key to tighten the screw at the back of the crossbar. (figure 5)
figure 5
5 mm hex key
Crossbar

Attach the upper pole

1. Screw the pole connector onto the lower pole.
2. Thread the other cable-management clip onto the upper pole.
3. Screw the upper pole into the pole connector. (figure 6)
figure 6
Upper pole
Cable-management clip
Pole connector
Instruction manual
8
