5. Place two washers over the mounting holes in the VESA monitor mount.
6. Insert two M4x12 mm screws or M5x12 mm screws through the washers, the
mounting holes in the VESA monitor mount, and into the back of the monitor.
(figure 12)
Warning! Do not over-tighten the screws. If you encounter resistance while you're
tightening the screws, stop tightening. Failure to do so could result in damage to the
monitor.
7. Repeat steps 1 to 6 to attach a monitor to the VESA monitor mount attached to the
lower pole.
figure 12
Monitor
Instruction manual
Washer
M4x12 mm screw
or
M5x12 mm screw
13
