DEMO MANUAL DC2328A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 5 C1, C3, C8, C25, C28
2 6 C2, C4, C5, C6, C16, C17
3 0 C19, C20, C21, C22, C23
4 1 C7
5 1 C9
6 1 C10
7 1 C11
8 1 C12
9 1 C13
10 0 C15
11 0 C18
12 0 C24
13 1 C26
14 1 C27
15 0 D1
16 0 D2
17 5 E1-E5
18 8 E6-E13
19 0 JP1
20 1 JP2
21 6 J1, J2, J3, J4, J5, J6
22 0 L1
23 0 L2
24 2 R1, R8
25 1 R2
26 1 R3
27 1 R4
28 3 R5, R10, R20
29 0 R7, R9, R12, R14, R19, R22, R23, R24
30 1 R13
31 1 R18
32 1 U1
33 1 XJP2
34 4 (STAND-OFF)
35 1
36 2
6
PART DESCRIPTION
CAP ., X7R, 4.7µF, 80V, 10%, 1210
CAP ., X7R, 10µF, 50V, 10%, 1210
CAP ., OPT, 1210
CAP ., ALUM., 100µF, 40V, 10x10.5
CAP ., X7R, 0.1µF, 100V, 10%, 0805
CAP ., X7R, 1µF, 50V, 10%, 0805
CAP ., X7R, 4.7nF, 50V, 10%, 0603
CAP ., X7R, 3.3nF, 50V, 10%, 0603
CAP ., X7R, 100nF, 50V, 10%, 0603
CAP ., OPT, 10X10.2
CAP ., OPT, 0805
CAP ., OPT, 0603
CAP ., OS-CON., 82µF, 35V, 8x11.9
CAP ., X5R, 1µF, 25V, 10%, 0603
DIODE, OPT, SOT23
DIODE, OPT, SMA
TESTPOINT, TURRET, .061"
TESTPOINT, TURRET, .094"
HEADER, OPT
HEADER, 1X3, 0.079
JACK, BANANA
IND, OPT, 1206
IND, OPT, IHLP3232CZ-01
RES., 240k, 0.1%, 0603
RES., 332Ω, 1%, 0603
RES., 102k, 1%, 0603
RES., 14k, 1%, 0603
Res., 10Ω, 1%, 0603
RES., OPT, 0603
RES., 124k, 1%, 0603
RES., 0Ω, 1%, 0603
I.C., LTM4651EY, BGA77-15X9X5.01
SHUNT, 0.079" CENTER
STAND-OFF , NYLON 0.50"
FAB, PRINTED CIRCUIT BOARD
STENCILS TOP AND BOTTOM
MANUFACTURER/PART NUMBER
MURATA, GRM32ER71K475KE14L
MURATA, GRM32ER71H106KA12L
OPT
SUN ELECTRONIC, 40HVP100M
MURATA, GRM21BR72A104KAC4K
MURATA, GRM21BR71H105KA12L
MURATA, GRM188R71H472KA01D
MURATA, GRM188R71H332KA01D
MURATA, GRM188R71H104KA93D
OPT
OPT
OPT
PANASONIC, 35SVPF82M
MURATA, GRM188R61E105KA12D
OPT
OPT
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
OPT
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 575-4
OPT
OPT
PANASONIC, ERA3AEB244V
VISHAY, CRCW0603332RFKEA
VISHAY, CRCW0603102KFKEA
VISHAY, CRCW060314K0FKEA
VISHAY, CRCW060310R0FKEA
OPT
VISHAY, CRCW0603124KFKEA
VISHAY, CRCW06030000Z0EA
LINEAR TECH., LTM4651EY#PBF
WURTH ELEKTRONIK, 60800213421
WURTH ELEKTRONIK, 702935000
DEMO CIRCUIT, 2328A
STENCIL DC2328A
