Configuration and Operation

The controller can be configured and operated by input keys according to the menus on the LCD display by
selecting proper ones and assigning values in the selected menu to input control information to the system.
Input information should immediately apply to the controller system once updated.

1. Input keys

The controller has 8 input keys including LCD, Mode, Menu, Enter, Up, Down, Left and Right.
Each key as respective functions as follows:
LCD
Mode
Menu
Enter
LCD key turns on and off the display.
Mode key switches the display to either operation mode or wave form display.
Menu key lets users change the menu display and go back to the previous menu.
Enter key applies designated values on the LCD display to the system.
Up key lets users go up or increase values in the selected menu on the LCD display.
Down key lets users go down or decrease values in the selected menu on the display.
Left key lets users move to the left in the selected menu.
Right key lets users move to the right in the selected menu.
