12.3 Spare parts of electric system

Pos. Art.-No.
EA00002175
1
2 EA00001949
3 EA00001197
4 ET00000211
5 EA00001550
6 EA00000778
7 EW00000793
8 EW00000788
9 EW00000590
EW00000591
Pos. 13 – 17 for Tempro primus C 90 not available !!
Tempro basic C 90 & Tempro primus C 90
Part
Board ST04
Board Display
Safety temperature limiter
Trafo 220, 400, 440,
480V /24VAC
F2=Fuse holder
1-pole
F2=Fuse 500V/0,5A
main switch 3x20A
+knob
K2=Contactor
4kW Pump
F1=Thermorelay
1,6 – 2,5 A
F1=Thermorelay
2,5 – 4,0 A
Pos. Art.-No.
EW00000768
10 EA00001244
11 EW00000721
12 T700001761
13 T500001204
14 EW00000512
15 EW00000513
16 EW00000514
17 EA00002072
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
Page 61
17
Part
F1=Thermorelay
4,0 – 6,0 A
Buzzer
K1=Contactor 9kW
Heating
Cover electric
Alarm cable
Press key
Button
Press key
splash guard
Press key
cap yellow
Interface board
