11.4.1 Engel RS232

T5 0000 1625
Screen
TxD (Green)
RxD (White)
GND (Brown)

11.4.2 Engel 20mA

T5 0000 1620
Screen
TxD + (White)
RxD - (Brown)

11.4.3 Demag 20mA

T5 0000 1624
TxD + (White)
RxD - (Brown)

11.4.4 Arburg 20mA (plug SubD 3 pol)

T5 0000 0312
TxD + (White)
RxD - (Brown)

11.4.5 Arburg 20mA (plug SubD 9 pol)

T5 0000 1621
TxD + (white)
RxD - (brown)
Tempro basic C 90 & Tempro primus C 90
1
3
2
7
IMM: SubD 25-pin
1
24
10
IMM: SubD 25-pin
19
13
IMM: SubD 25-pin
1
3
IMM: Arburg plug 3-pin
2
3
IMM: SubD 9pol. Stift
2
3
5
MTC: SubD 9-pin
3
7
4
6
MTC: SubD 9-pin
3
7
4
6
MTC: SubD 9-pin
3
7
4
6
MTC: SubD 9-pin
3
7
4
6
MTC: SubD 9pol. Stift
