7.5 Adjustment of set point value for cooling down function (SET2)

will be changed by 1°C, when keeping them pressed, the value will be increased in
cycles (5x slowly, then rapidly).
Simultaneously press the buttons
value of 40°C [100°F].
By pressing the key

7.6 Adjustment of tolerance limits (TOL)

value will be changed by 1°C, when keeping them pressed, the value will be
increased in cycles (5x slowly, then rapidly).
Simultaneously press the buttons
default value of 10°C [20°F].
By pressing the key
The tolerance monitoring is activated once the tolerance window has been
reached for the first time or upon expiry of time t1 (can be set in the configuration
menu).
Tempro basic C 90 & Tempro primus C 90
Press the button
for the cooling-down function set value 2.
The LED "SET2" is illuminated and the set value set
last is displayed.
This setpoint value may be changed upwards by
pressing the key
key .
The adjustment range is 10° - 90°C. [50 – 200°F].
Upon short actuation of the keys, the setpoint value
and
the selected value will be stored.
By pressing the key
mode for the tolerance limits.
The LED „TOL" will be illuminated and the most
recently adjusted tolerance value will be displayed.
This tolerance value may be changed upwards by
pressing the key
key .
The adjustment range is 1° - 90°C.
[2 – 200°F].
Upon short actuation of the keys, the tolerance
and
the selected value will be stored.
twice to get to the input mode
or downwards by pressing the
to set the nominal value to the default
3x you enter the input
or downwards by pressing the
to set the nominal value to the
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
Page 26
