11.4.6 Ferromatik 20mA

T5 0000 1622
TxD + (White)
RxD - (Brown)

11.4.7 Krauss Maffei 20mA

T5 0000 1626
TxD + (White)
RxD - (Brown)

11.4.8 Battenfeld 20mA

T5 0000 1618
TxD + (White)
RxD - (Brown)
Other interfaces cables for other machine manufacturers and designs on request.
Tempro basic C 90 & Tempro primus C 90
13
19
IMM: SubD 25-pin
24
10
IMM: SubD 25-pin
housing HAN10A with adapter
2
3
IMM: SubD 9-pin
3
7
4
6
MTC: SubD 9-pin
3
7
4
6
MTC: SubD 9-pin
3
7
MTC: SubD 9-pin
