Wittmann Tempro basic C 90 Translation Of Original Operating Manual page 59

Pos. Article number
1 T8 0000 1205
1A MA 0000 0631
2,11,23 HV 0000 0182
primus C 90 HV 0000 0182
HV 0000 0107
HV 0000 0224
5 D9 0000 0862
6 HP 0000 0180
T7 0000 2034
HP 0000 0184
T7 0000 2045
6.1 HP 0000 0110
HP 0000 0111
6A T7 0000 0794
9 T8 0000 1430
T8 0000 1414
T8 0000 0940
T8 0000 1434
9A T7 0000 1860
10 D9 0000 0863
12 D9 0000 0864
14 EA 0000 1197
20 MA 0000 0507
22 T8 0000 0312
24 T7 0000 2001
25 T7 0000 2000
26 T7 0000 1938
26 T7 0000 2071
T8 0000 1294
T8 0000 1295
Tempro basic C 90 & Tempro primus C 90
Description
Heat exchanger (tank) cpl. with seal & drain plug
Profile seal L=1008mm
Solenoid valve filling (2) cooling (11) & venting (23) cpl.
Solenoid valve filling (2) cooling (11) WITHOUT 23
Anchor cpl. (core & spring,Viton)
Magnet coil:24V-50HZ
Level switch cpl.
Immersion pump Standard (3x380- 480V)
Immersion pump Standard (3x220V)
Immersion pump enhanced (3x380- 480V)
Immersion pump enhanced (3x220V)
Cap cpl. for Immersion pump Standard
Cap cpl. for Immersion pump enhanced
Seal pump
Heater element 9KW, 480V (+ pos. 9A)
Heater element 9kW, 3x380V-415V (+ pos. 9A)
Heater element 6kW, 3x440V-480V (+ pos. 9A)
Heater element 6kW, 3x200V-240V (+ pos. 9A)
Seal heater element
Cooling coil cpl.
Temperature sensor cpl.
Safety temperature limiter 130°
Swivel wheel (1Stk)
Coarse filter
Hose cold water supply - filling, L=255
Hose cold water supply – cooling, L=380
Front foil BASIC C90
Front foil PRIMUS C90
Side panel left side (front view)
Side panel right side ( front view)
BASIC & PRIMUS C90 V 3.0 english / 10.04.2012
Page 59
