Chapter 2

Recommendations

Observe the following recommendations while installing the SmarTrax system:
Use part numbers to identify parts.
Do not remove the plastic wrapping from a part until it is necessary for installation.
Do not remove plastic caps from a part until it is necessary for installation.

Tools Needed

Before beginning the installation process, it is a good idea to gather all the tools that you will need. These tools
include the following items:
Screwdrivers of various sizes
SAE Standard-sized wrenches
Allen wrenches
Utility knife
Drill
Drill bits
Side Cutters
Pliers

Point of Reference

The instructions in this manual assume that you are standing behind the machine, looking toward the cab.

Hydraulic Fittings

The following fitting types may be referenced in this manual:
Hydraulic Fitting Types
FIGURE 2.
JIC Fitting (M)
4
GVM Prowler ('08 & Newer, All 120' Booms) SmarTrax Installation Manual
SAE O-Ring Fitting (M)
ORFS Fitting (M)
